Single vs two stage ac vacuum pump: which one should you buy? A single stage pump suits a home garage AC job where the maker calls for a standard evacuation, while a two stage pump suits jobs where the system maker calls for a deeper vacuum. A single stage pump pulls air with one pumping stage. A two stage pump passes air through two pumping stages in series, so it can reach a deeper vacuum than a single stage pump of similar size. The four pumps featured below are all single stage pumps.
As an Amazon Associate I earn from qualifying purchases. GarageToolHQ earns a commission when you buy through links on our product pages, at no extra cost to you. Read our affiliate disclosure.
Below: how the stages differ, what the single stage pumps state, which jobs fit each type, and answers to common questions.
What single vs two stage ac vacuum pump means in the garage
A vacuum pump evacuates an AC system before refrigerant is added. Two listings below describe that job as removing moisture before refilling with refrigerant, and the listings describe diagnosing, recharging and servicing AC systems.
A single stage pump uses one rotary vane stage to draw air out of the system. The single stage pumps here state flow rates of 3 CFM, 3.5 CFM and 4.5 CFM, and two of them state a vacuum level. A two stage pump runs two stages in series, with the second stage backing the first, so the pair can reach a deeper vacuum where a system maker specifies a lower level.
Single stage pumps: what the listings state
Flow rate is the first figure to compare. The XtremepowerUS pump states 3 CFM, both VIVOHOME pumps state 3.5 CFM, and the Orion Motor Tech pump states 4.5 CFM. The listings do not state a draw-down time for every pump, so flow alone does not tell the whole story.
Vacuum level is the second figure. The VIVOHOME VH409 pump states a vacuum level of 5 Pa, reached in 3 minutes per its listing, and the Orion Motor Tech pump states a vacuum level of 37.5 microns, also given as 5 Pa. The other two pumps state no vacuum level figure. Power also differs: the XtremepowerUS and both VIVOHOME pumps state 1/4 HP, the VH409 also states 180W and 1440 r/min, and the Orion Motor Tech pump states a 1/3 hp motor.
Refrigerant compatibility is stated per pump. The XtremepowerUS listing states R12, R22, R134a and R410a. Both VIVOHOME listings state R134a, R12, R22, R502 and R410a, with the VH409 noting that R410a needs a 5/16-inch adapter, not included, and the VH453 stating R410a fitting adapters from 1/4 in to 5/16 in. The Orion Motor Tech listing states R12, R22, R134a, R410a and R502.
| Pump | Flow | Vacuum level | Power | Weight | Kit |
|---|---|---|---|---|---|
| Orion Motor Tech Single Stage Pump | 4.5 CFM | 37.5 microns (5 Pa) | 1/3 hp | 9.77 pounds | Oil included, gloves, Teflon tape |
| VIVOHOME VH409 Single Stage Pump | 3.5 CFM | 5 Pa | 1/4 HP, 180W | 11.4 pounds | Oil bottle, no gauge set stated |
| VIVOHOME VH453 Single Stage Pump Kit | 3.5 CFM | Not stated | 1/4 HP | 18.7 pounds | Oil, gauge set, thermometer, hoses |
| XtremepowerUS Single Stage Pump Set | 3 CFM | Not stated | 1/4 HP | 10 pounds | Oil bottle, gauge set, hoses, bag |
The gear: single stage pumps in this guide, ranked
Orion Motor Tech Single Stage Pump
The Orion Motor Tech pump ranks first here on stated flow and vacuum level. It states a 4.5 CFM flow rate from a 1/3 hp all-copper motor and a vacuum level of 37.5 microns, given as 5 Pa. It states a reinforced aluminum alloy casing, an intake filter and trap, a sight glass and scale for oil level, and a nonslip handle. Item weight is stated as 9.77 pounds, and it fits 1/4-inch, 1/2-inch and 3/8-inch hoses. The kit includes oil, gloves for oil refill and Teflon tape.
One contradiction needs care: the spec table gives an item model number of 1 CFM, while the title and bullets state 4.5 CFM. Trust the title and bullets. Who it is for: owners who want the highest stated flow here and a stated vacuum level of 37.5 microns (5 Pa). Who should skip it: owners who want a gauge set in the kit.
VIVOHOME VH409 Single Stage Pump
The VIVOHOME VH409 pump ranks second here, on its stated vacuum level and motor protection. It states a 1/4 HP motor running at 1440 r/min, a flow rate of 3.5 CFM and a vacuum level of 5 Pa in 3 minutes. It states motor current protection, a one-piece die-cast aluminum housing, a four-pole pure copper motor, a 304 stainless steel coarse filter, a cotton layer filter at the exhaust port, an oil viewing window, a bottom oil drain valve, a cooling fan, a non-slip base and low-noise operation at approximately 65 dB. Item weight is stated as 11.4 pounds, and voltage is stated as 110V.
Who it is for: owners who want a stated vacuum level with motor protection for AC maintenance. Who should skip it: owners who want a gauge set in the box, or an R410a adapter included in the box, which the listing notes is not included.
VIVOHOME VH453 Single Stage Pump Kit
The VIVOHOME VH453 pump ranks third as a kit, rather than on vacuum level, which its listing does not state. It states a 3.5 CFM flow rate, a die-cast aluminum housing, an anti-slip rubber base, an ergonomic grip handle, a cooling fan, an oil sight glass, a bottom oil drain valve and a bottle of vacuum oil stated as 0.35 qt. and 330 ml. The gauge set states large viewing glasses, color-coded gauges and a thermometer, with a carrying bag, and the hoses state red for high-pressure, blue for low-pressure and yellow for filling. Item weight is stated as 18.7 pounds, and voltage is stated as 110 volts.
Who it is for: owners who want a pump plus gauge set, thermometer and hoses in one kit. Who should skip it: owners who want a stated vacuum level figure, which this listing does not give, or the lowest-weight kit here.
XtremepowerUS Single Stage Pump Set
The XtremepowerUS pump ranks fourth on stated flow, at 3 CFM, but it is a complete set after the VH453 kit. It states a 1/4 HP 1-stage rotary pump, an internal high volume cooling fan, a die-cast aluminum alloy casing, brass fitting safety caps against oil leaks, a simple oil fill port and an oil drain plug beneath the oil reservoir. The set includes a gauge set, an R134 can tap, an oil bottle, accessories, a storage bag and a multicolored set of 36-inch hoses. Item weight is stated as 10 pounds, and voltage is stated as 115 volts.
Who it is for: owners who want a pump, gauge set, can tap and storage bag together at the lowest stated flow here. Who should skip it: owners who want a stated vacuum level figure, a stated noise figure, or R502 compatibility.
Which type fits which job
For a car or mini split AC service where the system maker calls for a standard evacuation, a single stage pump from this guide matches the jobs the listings describe, such as removing moisture before refrigerant refill and diagnosing, recharging and servicing AC systems. For a job where the maker specifies a vacuum level deeper than the stated single stage figures here, a two stage pump is the tool to check. Where no vacuum level is specified, flow, kit contents and refrigerant compatibility are the practical differences above.
Check the manual before the first job, and check the pump listing for adapter needs. The VH409 listing notes a separate adapter for R410a, while the VH453 listing states R410a fitting adapters in the kit. A pump that needs an adapter the kit does not include is not ready until that adapter is added.
Drain the tank after use so water does not rust it from the inside, never exceed the tool's rated pressure, wear eye protection, and run 240V units on the circuit the manual calls for. Do not run a gas engine compressor in a closed garage. Read our Safety Disclaimer.
Frequently Asked Questions
Can a single stage pump evacuate an AC system?
Yes. Two listings here state that they remove moisture before refilling with refrigerant, and the listings describe diagnosing, recharging and servicing AC systems. The VH409 listing states a vacuum level of 5 Pa in 3 minutes, and the Orion Motor Tech listing states 37.5 microns, given as 5 Pa.
Do I need a two stage pump for a car AC?
Not necessarily. The single stage pumps here state automotive AC use, with refrigerant lists that include R134a and, for most of them, R12, R22, R410a and R502. A two stage pump is the choice where the maker calls for a deeper vacuum than the single stage figures stated here.
What CFM do I need?
Use the stated flows here as the comparison. The pumps state 3 CFM, 3.5 CFM and 4.5 CFM. The VH409 listing also states a vacuum level of 5 Pa in 3 minutes, for that pump only. The other listings state no draw-down time, so do not assume the same time from a different flow figure.
What refrigerants do these pumps support?
Each listing states its own list. The XtremepowerUS listing states R12, R22, R134a and R410a. Both VIVOHOME listings state R134a, R12, R22, R502 and R410a, with adapter notes that differ between them. The Orion Motor Tech listing states R12, R22, R134a, R410a and R502.
Do these pumps include oil and gauges?
Oil is stated for all four: the XtremepowerUS set, the VH409 listing, the VH453 kit and the Orion Motor Tech kit all state oil. Gauges differ: the XtremepowerUS set and the VH453 kit state a manifold gauge set, while the VH409 and Orion Motor Tech listings state no gauge set.
