Bearing Puller vs Gear Puller: Which One Should You Buy?

A bearing puller and a gear puller do the same job with different grips. A bearing puller, usually a splitter or separator set, gets its knife-edge jaws behind the bearing and pushes it off the shaft. A gear puller, usually a two- or three-jaw puller, hooks the outside of a gear, pulley or bearing and draws it off. If the part has a shoulder to grip behind, the splitter wins; if it has an outer edge to hook, the jaw puller wins. The bearing puller vs gear puller choice comes down to what you can grab.

GarageToolHQ earns a commission when you buy through links on our product pages, at no extra cost to you. Read our affiliate disclosure.

Bearing puller vs gear puller: the difference

Bearing splitters work from behind. The Orion Motor Tech and DAYUAN sets both include 2 in and 3 in separator jaws with a 5 ton capacity: the tapered jaws wedge behind the bearing, then a yoke and forcing screw push the shaft through. Jaw pullers work from the front. The szdealhola two-jaw puller fastens its claws to the outside of the part with a screw locking feature and draws it off, with a stated pull range of 0.67 to 1.50 in (17-38mm). Slide hammers are the third option for blind holes: the Orion Motor Tech 8-piece set threads onto rear axle bearings from 1-1/4 in to 2-7/8 in IDs and hammers them out where no puller can reach behind.

The four tools in this guide, ranked

Orion Motor Tech bearing splitter set. The most complete splitter here: 2 in and 3 in separator jaws, 6 in yoke, forcing screw and extension screws, all in heat treated Cr-V steel with a black oxide finish, rated at 5 ton capacity. The knife-like taper gets behind bearings in tight spaces, and the listing states a 1 year warranty. Best first pick for wheel hub and axle bearings.

Orion Motor Tech slide hammer axle set. An 8-piece set for rear axle work: a 2.5 pound slide hammer with T handle, yoke, locknut, hook and three bearing puller adapters covering 1-1/4 to 1-7/8, 1-5/16 to 2-3/8 and 1-3/8 to 2-7/8 in IDs. Built from AISI 1045 medium carbon steel with a chrome-plated hammer, galvanized yoke and blackened adapters, with a 1 year warranty. The pick when the bearing sits in a blind bore.

DAYUAN 14-piece separator set. A 14-piece kit with 2 in and 3 in bearing separators, a 5 in puller cross-bar with a 6-1/4 in forcing screw, 4 and 5 in extension legs and a 6 in yoke, in drop-forged steel with a 5 ton capacity. Ships in a red blow-molded case. No warranty term is stated. A solid second splitter set for the money, minus the warranty.

szdealhola two-jaw puller. The only jaw puller here, sold as a bearing gear puller for 17-38mm parts with a 0.67 to 1.50 in pull range. The crossbar detaches with a socket wrench, the jaws are black oxidation carbon steel forged after high temperature quenching, and a screw locking feature fastens the claws before pulling. Weighs 13.4 ounces. No warranty term is stated. The pick for gears, pulleys and small bearings with an edge to hook.

When to use a bearing splitter

Use a splitter when you can get behind the part. Wheel hub bearings, axle bearings and press-fit bearings with a shoulder all suit the tapered jaws: the Orion Motor Tech set lists front and rear wheel hub axle shafts, gears, pulleys and steering wheels, and the DAYUAN set lists bearing removal and housing separation. The 5 ton capacity on both sets covers stubborn press fits. Splitters need room for the yoke and screw above the shaft, so check the reach before buying.

When to use a jaw puller

Use a jaw puller when the part has an outer edge to hook and nothing to get behind. Gears, pulleys and small bearings suit the two-jaw design: the szdealhola lists automobile, motorcycle, electric car and agricultural machinery bearings and gears. Match the pull range to the part: 0.67 to 1.50 in here. Jaw pullers can scar the part edge if the claws slip, so seat them squarely and tighten the screw lock before pulling.

Fit and reach

Pullers fail when they cannot reach or span the part. The Orion Motor Tech splitter set lists a 6 in yoke with a 7-1/5 in forcing screw, four 4-1/3 in extension screws, four 5-1/3 in extension screws and two 5-3/5 in L-type legs. The DAYUAN set lists a 5 in cross-bar with a 6-1/4 in forcing screw and 4 in and 5 in extension legs. Measure the shaft length and the bearing diameter first, then confirm the yoke clears the shaft end with room for the screw to travel.

Frequently Asked Questions

Can I use a bearing puller on a gear?

A jaw puller sold for both, like the szdealhola bearing gear puller, handles gears and bearings within its 0.67 to 1.50 in range. A splitter set grips from behind, which suits bearings better than gears.

What size puller do I need?

Match the tool to the part. The splitter sets cover bearings with 2 in and 3 in separator jaws; the slide hammer adapters cover 1-1/4 in to 2-7/8 in IDs; the two-jaw puller covers 17-38mm parts. Measure the part before ordering.

Do I need a slide hammer?

Mostly for blind bores. When a bearing sits in a housing with nothing to push against, the slide hammer threads on and hammers it out; the Orion Motor Tech listing also describes flange-type axle pulling and seal pulling with the same set. For bearings on an open shaft, a splitter or jaw puller does the job.

Is 5 ton capacity enough?

Both splitter sets here state a 5 ton capacity, which the listings describe as suitable for professional and home use on vehicles, ATVs and light trucks. For larger industrial press fits, look for a bigger rated set.

Will a two-jaw puller damage the part?

It can mark the edge if the claws slip. Seat both jaws squarely, use the screw locking feature, and pull straight. If the part cannot take any marking, a splitter behind the race is kinder.
